| kali@kali:~/CTFs/tryhackme/Reversing ELF$ r2 -d crackme6
Process with PID 16349 started...
= attach 16349 16349
bin.baddr 0x00400000
Using 0x400000
asm.bits 64
Warning: r_bin_file_hash: file exceeds bin.hashlimit
[0x7ff486423090]> aaa
[x] Analyze all flags starting with sym. and entry0 (aa)
[x] Analyze function calls (aac)
[x] Analyze len bytes of instructions for references (aar)
[x] Check for objc references
[x] Check for vtables
[TOFIX: aaft can't run in debugger mode.ions (aaft)
[x] Type matching analysis for all functions (aaft)
[x] Propagate noreturn information
[x] Use -AA or aaaa to perform additional experimental analysis.
[0x7ff486423090]> afl
0x00400490 1 41 entry0
0x00400470 1 6 sym.imp.__libc_start_main
0x004004c0 4 41 sym.deregister_tm_clones
0x004004f0 4 57 sym.register_tm_clones
0x00400530 3 28 entry.fini0
0x00400550 4 45 -> 42 entry.init0
0x004007d0 1 2 sym.__libc_csu_fini
0x004007d4 1 9 sym._fini
0x004006d1 4 64 sym.compare_pwd
0x00400760 4 101 sym.__libc_csu_init
0x00400711 4 74 main
0x0040057d 28 340 sym.my_secure_test
0x00400418 3 26 sym._init
0x00400480 1 6 loc.imp.__gmon_start
0x00400450 1 6 sym.imp.puts
0x00400460 1 6 sym.imp.printf
[0x7ff486423090]> pdf @main
; DATA XREF from entry0 @ 0x4004ad
┌ 74: int main (int argc, char **argv, char **envp);
│ ; var int64_t var_10h @ rbp-0x10
│ ; var int64_t var_4h @ rbp-0x4
│ ; arg int argc @ rdi
│ ; arg char **argv @ rsi
│ 0x00400711 55 push rbp
│ 0x00400712 4889e5 mov rbp, rsp
│ 0x00400715 4883ec10 sub rsp, 0x10
│ 0x00400719 897dfc mov dword [var_4h], edi ; argc
│ 0x0040071c 488975f0 mov qword [var_10h], rsi ; argv
│ 0x00400720 837dfc02 cmp dword [var_4h], 2
│ ┌─< 0x00400724 741b je 0x400741
│ │ 0x00400726 488b45f0 mov rax, qword [var_10h]
│ │ 0x0040072a 488b00 mov rax, qword [rax]
│ │ 0x0040072d 4889c6 mov rsi, rax
│ │ 0x00400730 bf10084000 mov edi, str.Usage_:__s_password__Good_luck__read_the_source ; 0x400810 ; "Usage : %s password\nGood luck, read the source\n"
│ │ 0x00400735 b800000000 mov eax, 0
│ │ 0x0040073a e821fdffff call sym.imp.printf ; int printf(const char *format)
│ ┌──< 0x0040073f eb13 jmp 0x400754
│ │└─> 0x00400741 488b45f0 mov rax, qword [var_10h]
│ │ 0x00400745 4883c008 add rax, 8
│ │ 0x00400749 488b00 mov rax, qword [rax]
│ │ 0x0040074c 4889c7 mov rdi, rax
│ │ 0x0040074f e87dffffff call sym.compare_pwd
│ │ ; CODE XREF from main @ 0x40073f
│ └──> 0x00400754 b800000000 mov eax, 0
│ 0x00400759 c9 leave
└ 0x0040075a c3 ret
[0x7ff486423090]> pdf @sym.comare_pwd
Invalid address (sym.comare_pwd)
|ERROR| Invalid command 'pdf @sym.comare_pwd' (0x70)
[0x7ff486423090]> pdf @sym.compare_pwd
; CALL XREF from main @ 0x40074f
┌ 64: sym.compare_pwd (int64_t arg1);
│ ; var int64_t var_8h @ rbp-0x8
│ ; arg int64_t arg1 @ rdi
│ 0x004006d1 55 push rbp
│ 0x004006d2 4889e5 mov rbp, rsp
│ 0x004006d5 4883ec10 sub rsp, 0x10
│ 0x004006d9 48897df8 mov qword [var_8h], rdi ; arg1
│ 0x004006dd 488b45f8 mov rax, qword [var_8h]
│ 0x004006e1 4889c7 mov rdi, rax
│ 0x004006e4 e894feffff call sym.my_secure_test
│ 0x004006e9 85c0 test eax, eax
│ ┌─< 0x004006eb 750c jne 0x4006f9
│ │ 0x004006ed bfe8074000 mov edi, str.password_OK ; 0x4007e8 ; "password OK"
│ │ 0x004006f2 e859fdffff call sym.imp.puts ; int puts(const char *s)
│ ┌──< 0x004006f7 eb16 jmp 0x40070f
│ │└─> 0x004006f9 488b45f8 mov rax, qword [var_8h]
│ │ 0x004006fd 4889c6 mov rsi, rax
│ │ 0x00400700 bff4074000 mov edi, str.password___s__not_OK ; 0x4007f4 ; "password \"%s\" not OK\n"
│ │ 0x00400705 b800000000 mov eax, 0
│ │ 0x0040070a e851fdffff call sym.imp.printf ; int printf(const char *format)
│ │ ; CODE XREF from sym.compare_pwd @ 0x4006f7
│ └──> 0x0040070f c9 leave
└ 0x00400710 c3 ret
[0x7ff486423090]> pdf @sym.my_secure_test
; CALL XREF from sym.compare_pwd @ 0x4006e4
┌ 340: sym.my_secure_test (int64_t arg1);
│ ; var int64_t var_8h @ rbp-0x8
│ ; arg int64_t arg1 @ rdi
│ 0x0040057d 55 push rbp
│ 0x0040057e 4889e5 mov rbp, rsp
│ 0x00400581 48897df8 mov qword [var_8h], rdi ; arg1
│ 0x00400585 488b45f8 mov rax, qword [var_8h]
│ 0x00400589 0fb600 movzx eax, byte [rax]
│ 0x0040058c 84c0 test al, al
│ ┌─< 0x0040058e 740b je 0x40059b
│ │ 0x00400590 488b45f8 mov rax, qword [var_8h]
│ │ 0x00400594 0fb600 movzx eax, byte [rax]
│ │ 0x00400597 3c31 cmp al, 0x31 ; 49
│ ┌──< 0x00400599 740a je 0x4005a5
│ │└─> 0x0040059b b8ffffffff mov eax, 0xffffffff ; -1
│ │┌─< 0x004005a0 e92a010000 jmp 0x4006cf
│ └──> 0x004005a5 488b45f8 mov rax, qword [var_8h]
│ │ 0x004005a9 4883c001 add rax, 1
│ │ 0x004005ad 0fb600 movzx eax, byte [rax]
│ │ 0x004005b0 84c0 test al, al
│ ┌──< 0x004005b2 740f je 0x4005c3
│ ││ 0x004005b4 488b45f8 mov rax, qword [var_8h]
│ ││ 0x004005b8 4883c001 add rax, 1
│ ││ 0x004005bc 0fb600 movzx eax, byte [rax]
│ ││ 0x004005bf 3c33 cmp al, 0x33 ; 51
│ ┌───< 0x004005c1 740a je 0x4005cd
│ │└──> 0x004005c3 b8ffffffff mov eax, 0xffffffff ; -1
│ │┌──< 0x004005c8 e902010000 jmp 0x4006cf
│ └───> 0x004005cd 488b45f8 mov rax, qword [var_8h]
│ ││ 0x004005d1 4883c002 add rax, 2
│ ││ 0x004005d5 0fb600 movzx eax, byte [rax]
│ ││ 0x004005d8 84c0 test al, al
│ ┌───< 0x004005da 740f je 0x4005eb
│ │││ 0x004005dc 488b45f8 mov rax, qword [var_8h]
│ │││ 0x004005e0 4883c002 add rax, 2
│ │││ 0x004005e4 0fb600 movzx eax, byte [rax]
│ │││ 0x004005e7 3c33 cmp al, 0x33 ; 51
│ ┌────< 0x004005e9 740a je 0x4005f5
│ │└───> 0x004005eb b8ffffffff mov eax, 0xffffffff ; -1
│ │┌───< 0x004005f0 e9da000000 jmp 0x4006cf
│ └────> 0x004005f5 488b45f8 mov rax, qword [var_8h]
│ │││ 0x004005f9 4883c003 add rax, 3
│ │││ 0x004005fd 0fb600 movzx eax, byte [rax]
│ │││ 0x00400600 84c0 test al, al
│ ┌────< 0x00400602 740f je 0x400613
│ ││││ 0x00400604 488b45f8 mov rax, qword [var_8h]
│ ││││ 0x00400608 4883c003 add rax, 3
│ ││││ 0x0040060c 0fb600 movzx eax, byte [rax]
│ ││││ 0x0040060f 3c37 cmp al, 0x37 ; 55
│ ┌─────< 0x00400611 740a je 0x40061d
│ │└────> 0x00400613 b8ffffffff mov eax, 0xffffffff ; -1
│ │┌────< 0x00400618 e9b2000000 jmp 0x4006cf
│ └─────> 0x0040061d 488b45f8 mov rax, qword [var_8h]
│ ││││ 0x00400621 4883c004 add rax, 4
│ ││││ 0x00400625 0fb600 movzx eax, byte [rax]
│ ││││ 0x00400628 84c0 test al, al
│ ┌─────< 0x0040062a 740f je 0x40063b
│ │││││ 0x0040062c 488b45f8 mov rax, qword [var_8h]
│ │││││ 0x00400630 4883c004 add rax, 4
│ │││││ 0x00400634 0fb600 movzx eax, byte [rax]
│ │││││ 0x00400637 3c5f cmp al, 0x5f ; 95
│ ┌──────< 0x00400639 740a je 0x400645
│ │└─────> 0x0040063b b8ffffffff mov eax, 0xffffffff ; -1
│ │┌─────< 0x00400640 e98a000000 jmp 0x4006cf
│ └──────> 0x00400645 488b45f8 mov rax, qword [var_8h]
│ │││││ 0x00400649 4883c005 add rax, 5
│ │││││ 0x0040064d 0fb600 movzx eax, byte [rax]
│ │││││ 0x00400650 84c0 test al, al
│ ┌──────< 0x00400652 740f je 0x400663
│ ││││││ 0x00400654 488b45f8 mov rax, qword [var_8h]
│ ││││││ 0x00400658 4883c005 add rax, 5
│ ││││││ 0x0040065c 0fb600 movzx eax, byte [rax]
│ ││││││ 0x0040065f 3c70 cmp al, 0x70 ; 112
│ ┌───────< 0x00400661 7407 je 0x40066a
│ │└──────> 0x00400663 b8ffffffff mov eax, 0xffffffff ; -1
│ │┌──────< 0x00400668 eb65 jmp 0x4006cf
│ └───────> 0x0040066a 488b45f8 mov rax, qword [var_8h]
│ ││││││ 0x0040066e 4883c006 add rax, 6
│ ││││││ 0x00400672 0fb600 movzx eax, byte [rax]
│ ││││││ 0x00400675 84c0 test al, al
│ ┌───────< 0x00400677 740f je 0x400688
│ │││││││ 0x00400679 488b45f8 mov rax, qword [var_8h]
│ │││││││ 0x0040067d 4883c006 add rax, 6
│ │││││││ 0x00400681 0fb600 movzx eax, byte [rax]
│ │││││││ 0x00400684 3c77 cmp al, 0x77 ; 119
│ ────────< 0x00400686 7407 je 0x40068f
│ └───────> 0x00400688 b8ffffffff mov eax, 0xffffffff ; -1
│ ┌───────< 0x0040068d eb40 jmp 0x4006cf
│ ────────> 0x0040068f 488b45f8 mov rax, qword [var_8h]
│ │││││││ 0x00400693 4883c007 add rax, 7
│ │││││││ 0x00400697 0fb600 movzx eax, byte [rax]
│ │││││││ 0x0040069a 84c0 test al, al
│ ────────< 0x0040069c 740f je 0x4006ad
│ │││││││ 0x0040069e 488b45f8 mov rax, qword [var_8h]
│ │││││││ 0x004006a2 4883c007 add rax, 7
│ │││││││ 0x004006a6 0fb600 movzx eax, byte [rax]
│ │││││││ 0x004006a9 3c64 cmp al, 0x64 ; 100
│ ────────< 0x004006ab 7407 je 0x4006b4
│ ────────> 0x004006ad b8ffffffff mov eax, 0xffffffff ; -1
│ ────────< 0x004006b2 eb1b jmp 0x4006cf
│ ────────> 0x004006b4 488b45f8 mov rax, qword [var_8h]
│ │││││││ 0x004006b8 4883c008 add rax, 8
│ │││││││ 0x004006bc 0fb600 movzx eax, byte [rax]
│ │││││││ 0x004006bf 84c0 test al, al
│ ────────< 0x004006c1 7407 je 0x4006ca
│ │││││││ 0x004006c3 b8ffffffff mov eax, 0xffffffff ; -1
│ ────────< 0x004006c8 eb05 jmp 0x4006cf
│ ────────> 0x004006ca b800000000 mov eax, 0
│ │││││││ ; XREFS: CODE 0x004005a0 CODE 0x004005c8 CODE 0x004005f0 CODE 0x00400618 CODE 0x00400640 CODE 0x00400668
│ │││││││ ; XREFS: CODE 0x0040068d CODE 0x004006b2 CODE 0x004006c8
│ └└└└└└└─> 0x004006cf 5d pop rbp
└ 0x004006d0 c3 ret
|
